Phoenix Contact TRIO Series SMPS - Industrial Power Supplies
Product Details:
- Power Factor >0.9
- Humidity % up to 95% (non-condensing)
- Connector Type Screw Connection
- Efficiency >89%
- Shape Rectangular
- Insulation Material Polyamide (Housing)
- IP Rating IP20
- Click to View more
X
Phoenix Contact TRIO Series SMPS - Industrial Power Supplies Product Specifications
- Screw Terminal
- Industrial Automation, Machine Building, Control Panels
- -25°C to +70°C
- Reliable, Maintenance-Free, High MTBF
- Overload, Short Circuit, Overvoltage
- 870 g
- YES
- Metal
- DIN Rail
- Powder Coated
- 1
- 85-264 V AC / 110-350 V DC
- Single Phase
- DC
- Screw Connection
- 130 x 45 x 125 mm
- up to 95% (non-condensing)
- As per load
- >0.9
- Switch Mode Power Supply (SMPS)
- Rectangular
- IP20
- Polyamide (Housing)
- Compact
- 24 V DC
- >89%
- 47-63 Hz
- Grey
- Convection
- LED
- No
- < 150 mVpp
- 5 A
- 3.75 kV AC (input/output)
- Yes (for redundancy)
- EN 60068-2-6
- > 500,000 h (IEC 61709)
- 22.5...29.5 V DC
- >20 ms (at full load)
Product Description
Single-Phase Power Supplies
| Model / Booking Code | Output Voltage & Current | Description |
|---|---|---|
| TRIO-PS/1AC/24DC/2.5 (2866268) | 24V DC, 2.5A | Single-phase power supply (2.5A, 24V DC) |
| TRIO-PS/1AC/24DC/5 (2866310) | 24V DC, 5A | Reliable single-phase power supply |
| TRIO-PS/1AC/24DC/10 (2866323) | 24V DC, 10A | High-efficiency single-phase power supply |
| TRIO-PS/1AC/24DC/20 (2866381) | 24V DC, 20A | Industrial single-phase power supply |
Industrial-Grade Reliability
Phoenix Contact TRIO Series SMPS is engineered for sustained performance in industrial environments, offering high reliability with an MTBF exceeding 500,000 hours. Its robust build, vibration resistance (EN 60068-2-6), and a comprehensive range of protections (overload, short circuit, overvoltage, and overheating) ensure continuous, maintenance-free operation.
Flexible and Safe Power Supply
With adjustable output (22.5 - 29.5 V DC), parallel operation capability for redundancy, and a high input voltage range, the TRIO Series is fit for diverse installations. Status indication via LED and IP20-rated housing provide operational clarity and safety, while convection cooling allows quiet, efficient functioning without requiring additional fans.
Effortless Installation and Maintenance
The compact, rectangular metal housing and DIN rail mounting allow for quick installation, even in tight spaces within control panels. Screw terminal connections ensure secure and straightforward wiring, and powder-coated finish enhances durability. Designed to operate in temperatures from -25C to +70C and up to 95% humidity, it's ideal for the tough requirements of Indian industries.
FAQ's of Phoenix Contact TRIO Series SMPS - Industrial Power Supplies:
Q: How do I install the Phoenix Contact TRIO Series SMPS in my control panel?
A: Installation is straightforward, thanks to its compact, rectangular design and DIN rail mounting. Simply secure the unit onto the DIN rail inside your control panel and connect the wires using the screw terminal connectors provided.Q: What protections does the TRIO Series SMPS offer for industrial environments?
A: The TRIO Series SMPS includes multiple protection features such as overload, short circuit, overvoltage, and overheating safeguards to ensure safe and reliable operation, even in demanding industrial settings.Q: When is parallel operation recommended for the TRIO Series SMPS?
A: Parallel operation is ideal when redundancy or increased load capacity is required. The TRIO Series supports this feature, allowing multiple units to be connected together to enhance reliability and avoid downtime.Q: What benefits does the high MTBF provide for my application?
A: An MTBF of over 500,000 hours means the TRIO Series power supply offers exceptional longevity and reduces the need for frequent replacement or maintenance, providing long-term cost savings and minimizing downtime.Q: Where can I use this SMPS within industrial automation?
A: This SMPS is suitable for industrial automation, machine building, and control panel applications, particularly where reliable and continuous power is necessary for mission-critical operations.Q: What is the adjustment range for the output voltage, and how is it set?
A: The output voltage can be adjusted between 22.5 V DC and 29.5 V DC using the trim potentiometer located on the unit, allowing for precise configuration to fit your system requirements.Q: How does convection cooling enhance the performance of this power supply?
A: Convection cooling ensures quiet, reliable heat dissipation without moving parts, which minimizes maintenance, improves efficiency, and extends the operational lifespan of the SMPS.Tell us about your requirement
