DELTA HMI
7900.00 - 58000.00 INR/Piece
Product Details:
- IP Rating IP65 (Front Panel)
- Speed Range ---
- Application Industrial Automation
- Drive Type ---
- Frequency 50/60Hz
- Processor Type ARM Cortex
- Sensor Type ---
- Click to View more
X
DELTA HMI Price And Quantity
- 1 Piece
- 7900.00 - 58000.00 INR/Piece
- 10% to 90% RH, Non-Condensing
- 128 MB Flash, 64 MB RAM
- DOPSoft
- 50,000 hours (typ.)
- Real-Time OS
- SD Card Slot
- 65K Colors
- 800 x 480 pixels
- 4-wire analog resistive
- Buzzer
DELTA HMI Product Specifications
- 24 DC Volt (v)
- ---
- Panel Mount
- ---
- Automatic
- Single Phase
- RS232/RS485, Ethernet, USB
- Data Logging, Recipe Management, Password Protection, Multi-language Support
- Approx. 0.7 kg
- 7 Inch TFT LCD
- Touch Screen
- ---
- IP65 (Front Panel)
- Industrial Automation
- Any Industrial and non Industrial
- ---
- 0C to 50C (Operating)
- 50/60Hz
- 24 AC/DC, 230 AC Volt (v)
- Plastic and Metal
- ARM Cortex
- ---
- Yes
- Semi Automatic, Manual, Fully Automatic
- 10% to 90% RH, Non-Condensing
- 128 MB Flash, 64 MB RAM
- DOPSoft
- 50,000 hours (typ.)
- Real-Time OS
- SD Card Slot
- 65K Colors
- 800 x 480 pixels
- 4-wire analog resistive
- Buzzer
DELTA HMI Trade Information
- Cheque, Cash in Advance (CID), Cash Advance (CA)
- Yes
- Contact us for information regarding our sample policy
- Carton box packing available.
- Africa, Middle East, Asia
- All India
Product Description
We are engaged in Distribution of DELTA make of HMI Touch Pad & Keypad, These are easy to use, efficient and highly durable. these can also be customized according to the specifications of the customers.HMI Series:
- B Series: DOP-103BQ,DOP-B10E615
- DOP-100 Series:DOP-103WQ,DOP-107WV,DOP-107CV,DOP-107EV,DOP-107BV,DOP-107EG,DOP-110CS,DOP-110CS
- Keypad Series:TP02G-AS1
Display: 4.3'', 7'' and 10''
Price Range: 4000 to 29000
Versatile Touch Screen Display
The DELTA HMI features a 7-inch TFT LCD screen with a sharp 800 x 480 resolution and supports 65K colors for vivid visual feedback. Its analog resistive touch panel allows accurate control even in demanding industrial conditions, while the robust construction combines plastic and metal for durability. The front panel's IP65 rating safeguards against dust and water, ensuring longevity in harsh environments.
Powerful Performance and Expandability
Packed with an ARM Cortex processor, 128 MB Flash, 64 MB RAM, and accessible SD card expansion, the DELTA HMI handles data logging, recipe management, and smooth operation even during complex tasks. Its real-time operating system maximizes reliability, while proper memory allocation ensures quick interface response and long-term dependability for automation tasks.
Flexible Connectivity for Industrial Automation
Supporting RS232/RS485, Ethernet, and USB connections, the DELTA HMI integrates seamlessly into various industrial automation setups. Its compatibility with DOPSoft simplifies setup and maintenance, while remote control capabilities extend operational flexibility. Multi-language support and password protection also enhance adaptability and system security in global and sensitive applications.
FAQ's of DELTA HMI:
Q: How is the DELTA HMI typically installed?
A: The DELTA HMI is designed for panel mounting, allowing easy integration into control panels or industrial workstations. Its compact size and approximately 0.7 kg weight make installation straightforward in both new and existing systems.Q: What benefits does the 7-inch TFT LCD with 65K Color Display provide?
A: The vibrant TFT LCD offers clear, detailed visuals, supporting 65K colors for accurate graphical representation. This enhances usability and ensures that critical information is easy to interpret in complex industrial environments.Q: Where can the DELTA HMI be used?
A: This HMI is suitable for a broad range of settings, including manufacturing plants, process automation, and non-industrial environments. Its robust construction and IP65-rated front panel make it ideal for harsh or demanding installation sites found in industrial automation.Q: What software is used to program the DELTA HMI?
A: Programming and configuration are performed using DOPSoft, an intuitive software platform by DELTA. DOPSoft streamlines the creation of user interfaces, integration of automation features, and management of system resources.Q: When should you consider using the data logging and recipe management features?
A: Data logging and recipe management functions are particularly beneficial when there is a need to monitor process parameters or manage production variants frequently. Utilizing these features enables efficient record-keeping, quick changeovers, and improved process traceability.Q: How does the remote control feature enhance operation?
A: Remote control functionality allows users to access and manage the HMI from a distance, increasing convenience and safety. This can be especially useful for troubleshooting, ongoing maintenance, or when direct access to the panel is restricted.Q: What benefits does the Real-Time OS offer?
A: A Real-Time Operating System ensures immediate response to user input and process updates, crucial for precision and reliability in automation. This leads to improved system stability and consistent performance during critical operations.Tell us about your requirement
