nVent Hoffman Enclosure Mild Steel MAS1206030R5
12897.0 INR
Product Details:
- Material Mild Steel
- Surface Treatment Powder Coating
- Dimension (L*W*H) 1200 x 600 x 300 Millimeter (mm)
- Weight 49 Kilograms (kg)
- Color Light Gray
- Warranty 1 Year
- Click to View more
X
nVent Hoffman Enclosure Mild Steel MAS1206030R5 Price And Quantity
- 12897.0 INR
- 1
nVent Hoffman Enclosure Mild Steel MAS1206030R5 Product Specifications
- 49 Kilograms (kg)
- Powder Coating
- 1 Year
- 1200 x 600 x 300 Millimeter (mm)
- Light Gray
- Mild Steel
nVent Hoffman Enclosure Mild Steel MAS1206030R5 Trade Information
- 20 Per Day
- 1 Week
- No
- [, ]
- i, [, ', l, l, , I, n, d, a, ', ], A
- Industry Standards UL 508A Listed; Type 4, 12; File No. E92044 cUL Listed per CSA C22.2 No.0, No.0.4, No.14, No.94; Type 12; File No. E92044 NEMA/EEMAC Type 4, 12 CSA, File No. 1442951: Type 4, 12 IEC 62208 IP66 KEMA, GOST, Lloyds, DNV, Maritime, CE
Product Description
The mild steel single door wall mounted enclosure range, MAS, with a IP 66 protection degree, is available off the shelf in many different sizes. This enclosure range is well suited for many different applications. The risk for component failure, and with that unnecessary downtime, is eliminated as water and dust are prevented from entering the enclosure.Features
- Body: Folded and seam welded. Four 8.5 mm diameter holes for wall fixing, pressed out in 20.4 mm diameter 2 mm depressions, to allow air circulation around the rear part of the enclosure.
- Gland Plate Opening: Situated at the far rear of the enclosure, to make cabling onto the mounting plate easier.
- Protection: Complies with IP 66, TYPE 4, 12, IK 10. For outdoor installation, the use of a rain Hood, ARF, and 100% polyester paint coating plus corrosion protection primer is recommended. Resistance to corrosion must be taken into consideration for outdoor and indoor applications.
- Mounting plate: The mounting plate is marked vertically at 10 mm intervals, for easy horizontal positioning of equipment. On the top and bottom there are holes to facilitate cable fixing. Fixed onto M8 press welded studs to the rear of the enclosure. All sides, from 800 mm and above, are strengthened by folded edges. By using the AMG accessory, the mounting plate position can be adjusted to any depth.
- Material: Body: 1.2 mm mild steel for enclosures with a depth of 155 mm / 1.4 mm for enclosures with a depth of 210 or 260 mm / 1.5 mm for enclosures with a depth of 300 or 400 mm, or if a height or width is 1000 mm or greater. Gland plate: 1.4 mm mild steel. Door: 1.2 mm mild steel / 1.5 mm for enclosures with a height or width of 500 mm or greater / 2 mm for enclosures with a height or width of 800 mm or greater. Mounting plate: 2 mm galvanized steel.
- Lock: nVent HOFFMAN customized double-bit 3 mm lock, with 90 movement and anti-vibration mechanism. Two locks for 600 mm high to 800 mm high enclosures. Espagnolette three point locking for 1000 mm high enclosures and above. Other inserts are available as an accessory.
- Finish: RAL 7035 structured powder coating.
- Door: Surface mounted with 130 opening. Concealed removable hinges with captive pin. Hinges can be mounted to allow left or right hand opening. Inner M6 welded studs to mount door profiles MMDP, see delivery. Sealing is ensured by an injected one piece polyurethane gasket.
- Delivery: Enclosure with door and mounting plate (not included for item numbers ending with PER5). For height 600 mm and above, two MMDP door mounting profiles. Gland plate(s) with gasket(s), plastic double-bit 3 mm key, and mounting accessories. Metallic key, for height 1000 mm and above. Earthing facilities.
Specifications
Versatile Protection Solution
The nVent Hoffman MAS1206030R5 enclosure provides reliable and versatile protection for electrical components in demanding environments. Its robust mild steel construction and powder-coated finish help shield critical equipment from dust, moisture, and mechanical impact, making it suitable for various industrial and commercial settings.
Available Across India
Sourced from trusted dealers, distributors, exporters, and retailers, the nVent Hoffman enclosure is widely available throughout India. Customers can benefit from flexible purchase options and after-sales support, ensuring they receive the ideal enclosure for their specific project or operational requirements.
FAQ's of nVent Hoffman Enclosure Mild Steel MAS1206030R5:
Q: How is the nVent Hoffman MAS1206030R5 enclosure installed and used?
A: The enclosure is typically mounted to walls or control panels using its pre-drilled mounting holes. It is designed for housing sensitive electrical and electronic components to protect them from dust, moisture, and accidental contact in industrial environments.Q: What are the key benefits of the powder-coated mild steel construction?
A: The powder-coating process provides a durable, corrosion-resistant surface, while the mild steel offers excellent mechanical strength. This combination ensures extended service life and safeguards the enclosed equipment from harsh conditions.Q: When should I choose this enclosure for my application?
A: This enclosure is ideal when you require a robust, spacious housing solution for electrical components in manufacturing, automation, power distribution, or similar applications. Its size and durability make it well-suited for both indoor and sheltered outdoor installations.Q: Where can I buy the nVent Hoffman MAS1206030R5 in India?
A: You can purchase this enclosure from authorized dealers, distributors, exporters, retailers, suppliers, traders, and wholesalers across India. It is recommended to contact a certified provider to ensure product authenticity and warranty support.Q: What is the typical process for ordering and delivery?
A: To order, reach out to one of the authorized sellers with your requirements. Once your order is processed, the enclosure is securely packaged and shipped, with delivery timelines depending on your location and stock availability.Q: What warranty support is provided for this product?
A: The MAS1206030R5 enclosure comes with a 1-year manufacturer's warranty covering defects in material and workmanship, offering customers added confidence and peace of mind in their purchase.Tell us about your requirement
