nVent Hoffman Enclosure Mild Steel MAS1206040R5
14500.0 INR
Product Details:
- Material Mild Steel
- Surface Treatment Powder Coating
- Weight 23.1 Kilograms (kg)
- Color Light Gray
- Warranty 1 Year
- Click to View more
X
nVent Hoffman Enclosure Mild Steel MAS1206040R5 Price And Quantity
- 14500.0 INR
- 1
nVent Hoffman Enclosure Mild Steel MAS1206040R5 Product Specifications
- Mild Steel
- Powder Coating
- 23.1 Kilograms (kg)
- 1 Year
- Light Gray
nVent Hoffman Enclosure Mild Steel MAS1206040R5 Trade Information
- [, ', O, t, h, e, r, s, ', ]
- 20 Per Day
- 1 Week
- No
- [, ', A, l, l, , I, n, d, i, a, ', ]
- Industry Standards UL 508A Listed; Type 4, 12; File No. E92044 cUL Listed per CSA C22.2 No.0, No.0.4, No.14, No.94; Type 12; File No. E92044 NEMA/EEMAC Type 4, 12 CSA, File No. 1442951: Type 4, 12 IEC 62208 IP66 KEMA, GOST, Lloyds, DNV, Maritime, CE
Product Description
The mild steel single door wall mounted enclosure range, MAS, with a IP 66 protection degree, is available off the shelf in many different sizes. This enclosure range is well suited for many different applications. The risk for component failure, and with that unnecessary downtime, is eliminated as water and dust are prevented from entering the enclosure.Features
- Body: Folded and seam welded. Four 8.5 mm diameter holes for wall fixing, pressed out in 20.4 mm diameter 2 mm depressions, to allow air circulation around the rear part of the enclosure.
- Gland Plate Opening: Situated at the far rear of the enclosure, to make cabling onto the mounting plate easier.
- Protection: Complies with IP 66, TYPE 4, 12, IK 10. For outdoor installation, the use of a rain Hood, ARF, and 100% polyester paint coating plus corrosion protection primer is recommended. Resistance to corrosion must be taken into consideration for outdoor and indoor applications.
- Mounting plate: The mounting plate is marked vertically at 10 mm intervals, for easy horizontal positioning of equipment. On the top and bottom there are holes to facilitate cable fixing. Fixed onto M8 press welded studs to the rear of the enclosure. All sides, from 800 mm and above, are strengthened by folded edges. By using the AMG accessory, the mounting plate position can be adjusted to any depth.
- Material: Body: 1.2 mm mild steel for enclosures with a depth of 155 mm / 1.4 mm for enclosures with a depth of 210 or 260 mm / 1.5 mm for enclosures with a depth of 300 or 400 mm, or if a height or width is 1000 mm or greater. Gland plate: 1.4 mm mild steel. Door: 1.2 mm mild steel / 1.5 mm for enclosures with a height or width of 500 mm or greater / 2 mm for enclosures with a height or width of 800 mm or greater. Mounting plate: 2 mm galvanized steel.
- Lock: nVent HOFFMAN customized double-bit 3 mm lock, with 90 movement and anti-vibration mechanism. Two locks for 600 mm high to 800 mm high enclosures. Espagnolette three point locking for 1000 mm high enclosures and above. Other inserts are available as an accessory.
- Finish: RAL 7035 structured powder coating.
- Door: Surface mounted with 130 opening. Concealed removable hinges with captive pin. Hinges can be mounted to allow left or right hand opening. Inner M6 welded studs to mount door profiles MMDP, see delivery. Sealing is ensured by an injected one piece polyurethane gasket.
- Delivery: Enclosure with door and mounting plate (not included for item numbers ending with PER5). For height 600 mm and above, two MMDP door mounting profiles. Gland plate(s) with gasket(s), plastic double-bit 3 mm key, and mounting accessories. Metallic key, for height 1000 mm and above. Earthing facilities.
Specifications
Durable Mild Steel Construction
The MAS1206040R5 enclosure is fabricated from premium mild steel, providing exceptional structural integrity and resistance to mechanical stress. The powder-coated surface enhances its endurance and appearance, making it suitable for various industrial applications.
Reliable Protection and Easy Access
Powder-coated mild steel enclosures like MAS1206040R5 offer dependable protection for sensitive electrical and automation equipment. Its design allows straightforward mounting and maintenance, making it a favored choice among engineers and technicians.
Versatile Application Across Industries
With its standard light gray finish and sturdy build, the MAS1206040R5 is appropriate for installation in factories, workshops, and commercial spaces. Its adaptability ensures compatibility with numerous automation and control projects throughout India.
FAQ's of nVent Hoffman Enclosure Mild Steel MAS1206040R5:
Q: How is the nVent Hoffman MAS1206040R5 enclosure typically used?
A: The MAS1206040R5 enclosure is commonly employed to house electrical, control, and automation equipment in industrial and commercial environments, safeguarding sensitive components from dust, physical impact, and environmental factors.Q: What are the main benefits of choosing a powder-coated mild steel enclosure?
A: Powder coating on mild steel enhances corrosion and scratch resistance, ensuring longevity and maintaining a professional appearance. This makes the enclosure especially suitable for harsh industrial settings where durability is essential.Q: When should I consider replacing my current enclosure with the MAS1206040R5?
A: You should consider upgrading to the MAS1206040R5 if your existing enclosure lacks adequate protection, shows signs of corrosion, or does not meet your size or durability requirements.Q: Where can I purchase the nVent Hoffman MAS1206040R5 in India?
A: This enclosure is widely distributed across India through a network of authorized dealers, distributors, exporters, retailers, suppliers, traders, and wholesalers, making it accessible for a variety of business needs.Q: What is the process for installing the MAS1206040R5 enclosure?
A: Installation typically involves securely mounting the enclosure to a wall or other stable structure, arranging the internal components, and ensuring all connections meet safety and operational standards as per the manufacturer's guidelines.Q: How does the included warranty enhance the value of the MAS1206040R5?
A: The 1-year warranty provides assurance against manufacturing defects, giving you confidence in the product's quality and offering support in case any issues arise during regular use.Tell us about your requirement
